RideTech 1988-98 Chevy/GMC C1500 Complete Coilover Systems 11370201

In Stock

$4,380.00

Suspension Handling Package, 1988-98 Chevy/GMC C1500 Complete Coilover System, Tubular Control Arms, Steel, Black Powdercoated, Kit

In Stock

Did you like this product? Add to favorites now and follow the product.

Add to Wishlist

Have a Question? Ask a Specialist

+1 (917) 740-4358Start Live Chat

Low Prices

Price match guarantee

Guaranteed Fitment.

Always the correct part

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Description

Overview

Brand: RideTech

Manufacturer’s Part Number: 11370201

Part Type: Suspension Handling Packages

Product Line: RideTech 1988-98 Chevy/GMC C1500 Complete Coilover Systems

Summit Racing Part Number: ART-11370201

UPC: 840123506092

Front Coil Springs Included: Yes

Rear Coil Springs Included: Yes

Rear Leaf Springs Included: No

Front Shocks/Struts Included: Yes

Front Shock Type: Single adjustable monotube coilover

Rear Shocks/Struts Included: Yes

Rear Shock Type: Single adjustable monotube coilover

Front Sway Bar Included: Yes

Front Sway Bar Color: Black

Front Sway Bar Type: Solid

Front Sway Bar Diameter (in.): 1.500 in.

Rear Sway Bar Included: No

Tie Rod Sleeves Included: No

End Link Bushings Included: Yes

Rear Leaf Spring Bushings Included: No

Sway Bar Bushings Included: Yes

Upper Trailing Arms Included: Yes

Lower Trailing Arms Included: No

Trailing Arm Mount Braces Included: No

Panhard Bar Included: No

Torque Arm Included: No

Upper Control Arms Included: Yes

Lower Control Arms Included: Yes

Control Arm Style: Tubular

Control Arm Material: Steel

Control Arm Color: Black

Front Strut Tower Bar Included: No

K-Member Included: No

K-Member Support Brace Included: No

Rear Strut Tower Bar Included: No

Subframe Connectors Included: No

Chassis Stiffener Included: No

Calipers Included: No

Rotors Included: No

Brake Pads Included: No

Brake Lines Included: No

Wheel Studs Included: No

Center Link Included: No

Spindles Included: Yes

Inner Tie Rod Ends Included: No

Outer Tie Rod Ends Included: No

Bushing Material: Delrin®

Bushing Color: Black

Mounting Hardware Included: Yes

Quantity: Sold as a kit.

Notes: Fits models with 10-bolt rear differentials only.

RideTech 1988-98 Chevy/GMC C1500 Complete Coilover Systems

RideTech C1500 complete coilover systems include everything needed to create modern drivability with an aggressive stance for the 1988-98 Chevrolet and GMC C1500 trucks. The package contains front upper and lower StrongArm tubular A-arms, front and rear HQ Series coilover shocks, front sway bar, HD drop spindles, and rear wishbone with integrated C-notches. The benefit of a RideTech complete suspension system is that it removes all the guesswork as to which components to purchase—saving you time and money.

Overview of features, specs, and parts:

* Ride height is approximately 4 in. lower than stock in the front and 6 in. in the rear (coilovers add adjustability for rebound and ride height)
* Front coilover setup includes HQ Series shocks and bolt-on upper shock mounts to allow more ground clearance and maximum suspension travel
* HQ Series aluminum body shocks are a monotube design, rebound adjustable, and come with a 1,000,001 mile manufacturer warranty
* Upper StrongArm A-arms feature corrected ball joint angles for the lowered ride height, and the length has been altered to create more camber adjustment. Injection-molded Delrin bushings with 13 percent PTFE are used to reduce deflection and stiction. Also includes integrated brake line mounting brackets.
* Lower StrongArm A-arms feature a double-sheer lower shock mount for increased strength; the injection-molded Delrin bushings with 13 percent PTFE are used to reduce deflection and stiction. Also included are quality ball joints for a completely bolt-on experience.
* Front MuscleBar sway bar is included to reduce body roll and includes the Delrin liners to minimize suspension bind
* HD drop spindles are used to all the use of a longer stroke shock and improve suspension geometry and bump steer
* Bolt-on wishbone system greatly improves traction, handling, and ride quality. Installation does not require welding or major modifications to the bed floor.
— Includes patent-pending R-joint rod ends to eliminate binding and noise
— Wishbone upper link (rather than panhard bar) for zero lateral movement during suspension travel allows extremely tight wheel/tire fitment
— Optimized anti-squat, instant center and pinion angle migration for dramatic improvements in handling and traction
— Bolt-on C-notch reinforces OEM frame rails and features integrated suspension mounts
— Simple installation with minimal OEM rivet removal
