Cummins Onan 5500-Watt Propane Generator
The Cummins Onan RV QG 5500 LP 5.5HGJAB-1119 meets CARB and EPA Tier 4 Final and Phase IV standards and specifications required for all motorized recreational vehicle generator sets. For sale in all 50 states.
For Class A, Class B, and Class C RV Motorhomes, motorized vehicles and light commercial vehicle applications, the Cummins Onan 5500 LP Generator 5.5HGJAB-1119 starts and runs two 15,000 BTU air conditioners with a 1000-watt baseload of lights and appliances.
Cummins Onan 5500 LP Generator
The Cummins Onan RV QG 5500 LP meets CARB and EPA requirements in all 50 states for motorized vehicle applications including RV Motorhomes, Truck Campers, and RV Trailers. Cummins incorporates a digital voltage regulator, frequency regulation, one single-pole 30-Amp Circuit Breaker and one single-pole 20-Amp HACR breaker. Each 5500-Watt Propane Generator Set includes 120-inch-long output leads for connection to the RV Breaker Panel plus a sealed remote start connector. This RV QG 5500 LP weighs just 288 pounds and has a compact design of 33.6-inches wide x 22.2-inches deep x 16.7-inches high.
Go RVing in our national parks without worry. The Cummins Onan RV QG 5500 LP meets National Park Service sound level requirements of 60 dB(A) or less at 50 feet. Expect less than 69dB from 10 feet away as typical installations further lower the sound level. Vibration isolation makes the Onan 5500 LP Generator operation exceptionally smooth and quiet within the full housing. The spark-arresting muffler, enclosed within the integrated housing and steel base, is USDA Forest Service approved.
Cummins Onan 5500 Propane Generator
Microprocessor control with diagnostics and troubleshooting features protection for overcrank and field overload, over/under frequency and loss of AC signal, mechanical faults, and starter faults. The Cummins Onan 5500 Propane Generator set operates efficiently and includes a replaceable air cleaner, has automatic choke, and an electric solenoid positive LPG fuel shutoff. Remote rocker-switch starting from the remote panel with 12-volt 3-wire negative ground.
The RV QG 5500 LP comes with a 3-year limited warranty which includes a free 90-day minor adjustment policy and a lifetime drive warranty.
Package Includes the Onan 5500 Generator Manual.
Product Specifications
Model
Model Number; 5.5HGJAB-1119
Manufacturer; Onan RV
Made In USA; Yes
Rated Watts; 5.5kW
Rated Amps; 45.8
Voltage; 120V Single Phase
A/C Ton Rating; Single Roof AC
Decibel Rating; 67 dB(A) at 10ft
Type; Recreational Vehicle Generator
Series Name; Quiet Gas 5500 Series
Features
Starting System; Electric Start
Low Oil Alert; Yes
Hour Meter; No
Weight; 279 lbs
Dimensions; 33.6L x 22.2W x 16.7H
Warranty Information
Consumer Warranty; 3 Year Limited
Engine
Engine Brand; Cummins Onan OHV EH65V
Engine Size; 4-cycle OHV V-Twin
Engine RPM; 2400
Cooling System; Air Cooled
Alternator
Alternator Type; Brushed
Frequency; 60 Hz
Auto Voltage Regulation; Yes
Fuel
Fuel Type; Propane (LP)
Fuel Gauge; No
LP Consumption @ Full Load; 1.1 gal/h
LP Consumption @ Half Load; .8 gal/h
